- 11 excitation wavelengths
– Ar-Kr (Coherent Innova 70C Spectrum) : 457, 476, 488, 514, 531, 568, 647 nm
– He-Ne (integrated): 633 nm
– Diode: 785 nm
– Diode: 830 nm
– Nd-YAG: 1064 nm - Olympus BX microscope, 50x and 100x vis LWD lenses, 50x IR LWD lens
- NEW! Piezo XYZ stage (PI 730.3CD)
- Manual / motorized XY stages, manual / piezo Z axis
- DuoScan
- Peltier-cooled CCD / liquid nitrogen cooled InGaAs detector for IR range
- Linkam heating stage (RT to 1500°C)
- Diamond-anvil cell
- Available gratings: 300, 600, 1200, 1800 l/mm
- Electrochemical cell(s) for in-situ spektroelectrochemical measurements; controlled by µAutolab (Ecochemie/Metrohm)
- Cantilever beam bending apparatus for in-situ spectromechanical studies
— Installed 2008 —
|
|
